Main features
- Compact design
- Rugged housing
- IP65-rated protection
- Diverse mounting positions
- May be used as „simple apparatus“ in zones at risk of explosions
About
Technical Data
| Product code | 947 |
|---|---|
| Name | «Simple Apparatus» conformity to ATEX |
| Designation | Pressostat |
| Product category | Mechanical pressure switches |
| Measuring range | 1 ... 10 to 60 ... 600 bar |
| Measuring principle | Piston |
| Designation of application | Industrial pressostat |
| Applications | Potentially hazardous areas |
| Approval / conformity | EN60730-1/ EN60730-2-6: Typ 2.B.H EN60079-0, EN60079-11 Zone 1 and 2, 21 and 22 |
| Repeatability | ± 1.0 % FS typ. |
| Output signal | 1 Floating change-over contact (SPDT) |
| Media temperature | O-Ring NBR: -30°C ... +100°C O-Ring FKM: -15°C ... +150°C |
| Ambient temperature | -25°C ... 70°C |
Downloads Go to file downloads
Datasheet:
-
H72366g CN 947 Simple Apparatus conformity to ATEX Pressostatcn
pdf 453.8KB
-
H72366g DE 947 Simple Apparatus conformity to ATEX Pressostatde
pdf 392.1KB
-
H72366g EN 947 Simple Apparatus conformity to ATEX Pressostaten
pdf 390.7KB
-
H72366g ES 947 Simple Apparatus conformity to ATEX Pressostates
pdf 391.6KB
-
H72366g FR 947 Simple Apparatus conformity to ATEX Pressostatfr
pdf 391.6KB
-
H72366g IT 947 Simple Apparatus conformity to ATEX Pressostatit
pdf 391.1KB
-
H72366g JP 947 Simple Apparatus conformity to ATEX Pressostatjp
pdf 453KB
-
H72366g PL 947 Simple Apparatus conformity to ATEX Pressostatpl
pdf 392.7KB
-
H72366g PT 947 Simple Apparatus conformity to ATEX Pressostatpt
pdf 392.2KB
Manual:
Flyer:
-
H70921g CN 947 Simple Apparatus conformity to ATEX Pressostatcn
pdf 3.6MB
-
H70921g DE 947 Simple Apparatus conformity to ATEX Pressostatde
pdf 3.6MB
-
H70921g EN 947 Simple Apparatus conformity to ATEX Pressostaten
pdf 3.6MB
-
H70921g ES 947 Simple Apparatus conformity to ATEX Pressostates
pdf 3.6MB
-
H70921g FR 947 Simple Apparatus conformity to ATEX Pressostatfr
pdf 3.6MB
-
H70921g IT 947 Simple Apparatus conformity to ATEX Pressostatit
pdf 3.6MB
-
H70921g JP 947 Simple Apparatus conformity to ATEX Pressostatjp
pdf 3.6MB
-
H70921g PL 947 Simple Apparatus conformity to ATEX Pressostatpl
pdf 3.6MB
-
H70921g PT 947 Simple Apparatus conformity to ATEX Pressostatpt
pdf 3.6MB
Certificates:
