Main features
- Rugged aluminium housing
- Protection IP 65
- Diverse mounting positions
About
Technical Data
| Product code | 920/924/932 |
|---|---|
| Name | PD |
| Designation | Differential Pressure Pressostat |
| Product category | Mechanical pressure switches |
| Measuring range | -1 ... 6 to -1 ... 18 bar |
| Measuring principle | Bellow |
| Approval / conformity | ABS, BV, CCS, DNV-GL, KRS, LRS, RINA EN60730-1/ EN60730-2-6: Type 2.B.H |
| Repeatability | ± 1.0 % FS typ. |
| Output signal | 1 Floating change-over contact (SPDT) |
| Electrical connections | Screw terminal |
| Pressure connections | G1/4" f, G1/8" f, G1/2" m |
| Media temperature | -40°C ... +150°C |
| Ambient temperature | -25°C ... +70°C |
Downloads Go to file downloads
Datasheet:
-
H72253s CN 920 924 932 PD Differential Pressure Pressostatcn
pdf 642.3KB
-
H72253s DE 920 924 932 PD Differential Pressure Pressostatde
pdf 582.6KB
-
H72253s EN 920 924 932 PD Differential Pressure Pressostaten
pdf 1.5MB
-
H72253s ES 920 924 932 PD Differential Pressure Pressostates
pdf 582.4KB
-
H72253s FR 920 924 932 PD Differential Pressure Pressostatfr
pdf 1.5MB
-
H72253s IT 920 924 932 PD Differential Pressure Pressostatit
pdf 581.7KB
-
H72253s JP 920 924 932 PD Differential Pressure Pressostatjp
pdf 653.6KB
-
H72253s PL 920 924 932 PD Differential Pressure Pressostatpl
pdf 583.5KB
-
H72253s PT 920 924 932 PD Differential Pressure Pressostatpt
pdf 583KB
Manual:
-
H73256g Instruction Pressostat PD 9XXen
pdf 394.6KB
Certificates:
-
CE UKCA Declaration of conformity 9xxen
pdf 68.1KB
-
BV Pressostats 9xx Seriesen
pdf 1.1MB
-
CCS Pressure Switch 9xxen
pdf 268.1KB
-
RINA Pressure Switches 9xxen
pdf 1.7MB
