NAT 8252 Industrial Pressure Transmitter

Back to overview

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Main features

Smallest design
Completely welded steel sensor system without additional seals
Excellent long-term stability
Optional: 5-fold overpressure resistance
Optional: Switching output 1 or 2 PNP

About

The industrial pressure transmitter NAT 8252 features an exceptionally long-term stable thin-film-on-steel sensor cell with triple (optionally 5-fold) overpressure safety. Optionally, the NAT 8252 is available as a pressure switch with 1 or 2 switching outputs. The robust design and the wide temperature range from -40°C to +125°C qualify the NAT 8252 as the ideal solution for a wide range of demanding applications.

Technical Data

More Information
Product code	8252
Name	NAT
Designation	Industrial Pressure Transmitter
Product category	Pressure transmitters
Measuring range	0 ... 2.5 a 0 ... 700 bar 0 ... 30 a 0 ... 10000 psi
Measuring principle	Thin-film-on-steel
Applications	HVAC Hydraulics Machine tools Process technology Refrigeration Water treatment
Accuracy @ 25°C typ.	± 0.5 % FS typ.
Output signal	4 ... 20 mA, 0 ... 5 VDC, 1 ... 5 VDC, 1 ... 6 VDC, 0 ... 10 VDC and more, 0.5 ... 4.5 VDC ratiometric, Switching output: 1 or 2 PNP
Electrical connections	Industrial standard, contact distance 9.4 mm; M12x1; MIL-C 26482; Deutsch DT04-3P/4P; Cable
Pressure connections	G1/4" m; G1/4" m (Manometer); G1/4" m with integrated damping; G1/8" m, DIN3852-E; 1/4"NPT m; 1/4"NPT f; 1/8"NPT m; 7/16"-20UNF f, SAE J512; 7/16"-20UNF m, SAE4 (J1926); 7/16"-20UNF m, DIN3866; 9/16"-18UNF m, SAE6 (J1926); R1/4" m, DIN3858; R1/4" m, DIN29
Media temperature	–40°C ... +125°C
Ambient temperature	–40°C ... +125°C (Cable PVC 22: -5°C ... +60°C) (Cable PUR 24: -40°C ... +70°C) (Cable Radox Tenuis 88: -40°C ... +100°C)

Downloads Go to file downloads

Datasheet:

H72303ad CN 8252 NAT Industrial Pressure Transmitter
cn
pdf 1.3MB
H72303ad DE 8252 NAT Industrial Pressure Transmitter
de
pdf 1.2MB
H72303ad EN 8252 NAT Industrial Pressure Transmitter
en
pdf 1.2MB
H72303ad ES 8252 NAT Industrial Pressure Transmitter
es
pdf 1.2MB
H72303ad FR 8252 NAT Industrial Pressure Transmitter
fr
pdf 1.2MB
H72303ad IT 8252 NAT Industrial Pressure Transmitter
it
pdf 1.2MB
H72303ad JP 8252 NAT Industrial Pressure Transmitter
jp
pdf 1.3MB
H72303ad PL 8252 NAT Industrial Pressure Transmitter
pl
pdf 1.2MB
H72303ad PT 8252 NAT Industrial Pressure Transmitter
pt
pdf 1.2MB

Manual:

H73303u Instructions 8250 8252 8254 8256 8258 NHT NAT NAH NAE NAR Pressure Transmitter
en
pdf 539.9KB

Flyer:

H70666ad CN 8252 NAT Industrial Pressure Transmitter
cn
pdf 5MB
H70666ad DE 8252 NAT Industrial Pressure Transmitter
de
pdf 5MB
H70666ad EN 8252 NAT Industrial Pressure Transmitter
en
pdf 5MB
H70666ad ES 8252 NAT Industrial Pressure Transmitter
es
pdf 5MB
H70666ad FR 8252 NAT Industrial Pressure Transmitter
fr
pdf 5MB
H70666ad IT 8252 NAT Industrial Pressure Transmitter
it
pdf 5MB
H70666ad JP 8252 NAT Industrial Pressure Transmitter
jp
pdf 5MB
H70666ad PL 8252 NAT Industrial Pressure Transmitter
pl
pdf 5MB
H70666ad PT 8252 NAT Industrial Pressure Transmitter
pt
pdf 5MB

Certificates:

CE UKCA Declaration of conformity Pressure Transmitter
en
pdf 73.9KB

STEP files and software:

8252.XX.XX.30.02
en
STEP 288.4KB
825X.XX.XX.15.01
en
STEP 1.4MB
825X.XX.XX.15.02
en
STEP 513.2KB
825X.XX.XX.15.08
en
STEP 238.6KB
825X.XX.XX.15.22 24 88
en
STEP 382.2KB
825X.XX.XX.15.32
en
STEP 1.2MB
825X.XX.XX.15.35
en
STEP 1.3MB
825X.XX.XX.15.D3
en
STEP 1.6MB
825X.XX.XX.15.D4
en
STEP 1.3MB
825X.XX.XX.16.01
en
STEP 1.4MB
825X.XX.XX.16.02
en
STEP 505KB
825X.XX.XX.16.08
en
STEP 230.4KB
825X.XX.XX.16.22 24 88
en
STEP 374KB
825X.XX.XX.16.32
en
STEP 1.2MB
825X.XX.XX.16.35
en
STEP 1.3MB
825X.XX.XX.16.D3
en
STEP 1.6MB
825X.XX.XX.16.D4
en
STEP 1.3MB
825X.XX.XX.17.01
en
STEP 1.4MB
825X.XX.XX.17.02
en
STEP 523.5KB
825X.XX.XX.17.08
en
STEP 248.9KB
825X.XX.XX.17.22 24 88
en
STEP 392.5KB
825X.XX.XX.17.32
en
STEP 1.2MB
825X.XX.XX.17.35
en
STEP 1.3MB
825X.XX.XX.17.D3
en
STEP 1.6MB
825X.XX.XX.17.D4
en
STEP 1.3MB
825X.XX.XX.18.01
en
STEP 1.4MB
825X.XX.XX.18.02
en
STEP 488.5KB
825X.XX.XX.18.08
en
STEP 213.8KB
825X.XX.XX.18.22 24 88
en
STEP 357.5KB
825X.XX.XX.18.32
en
STEP 1.2MB
825X.XX.XX.18.35
en
STEP 1.3MB
825X.XX.XX.18.D3
en
STEP 1.6MB
825X.XX.XX.18.D4
en
STEP 1.3MB
825X.XX.XX.19.01
en
STEP 1.4MB
825X.XX.XX.19.02
en
STEP 503.8KB
825X.XX.XX.19.08
en
STEP 229.1KB
825X.XX.XX.19.22 24 88
en
STEP 372.8KB
825X.XX.XX.19.32
en
STEP 1.2MB
825X.XX.XX.19.35
en
STEP 1.3MB
825X.XX.XX.19.D3
en
STEP 1.6MB
825X.XX.XX.19.D4
en
STEP 1.3MB
825X.XX.XX.24.01
en
STEP 1.5MB
825X.XX.XX.24.02
en
STEP 548.2KB
825X.XX.XX.24.08
en
STEP 273.5KB
825X.XX.XX.24.22 24 88
en
STEP 417.1KB
825X.XX.XX.24.32
en
STEP 1.3MB
825X.XX.XX.24.35
en
STEP 1.3MB
825X.XX.XX.24.D3
en
STEP 1.6MB
825X.XX.XX.24.D4
en
STEP 1.3MB
825X.XX.XX.30.01
en
STEP 1.4MB
825X.XX.XX.30.02
en
STEP 494.6KB
825X.XX.XX.30.08
en
STEP 220KB
825X.XX.XX.30.22 24 88
en
STEP 363.6KB
825X.XX.XX.30.32
en
STEP 1.2MB
825X.XX.XX.30.35
en
STEP 1.3MB
825X.XX.XX.30.D3
en
STEP 1.6MB
825X.XX.XX.30.D4
en
STEP 1.3MB
825X.XX.XX.32.01
en
STEP 1.4MB
825X.XX.XX.32.02
en
STEP 532.1KB
825X.XX.XX.32.08
en
STEP 257.5KB
825X.XX.XX.32.22 24 88
en
STEP 401.1KB
825X.XX.XX.32.32
en
STEP 1.3MB
825X.XX.XX.32.35
en
STEP 1.3MB
825X.XX.XX.32.D3
en
STEP 1.6MB
825X.XX.XX.32.D4
en
STEP 1.3MB
825X.XX.XX.42.01
en
STEP 1.4MB
825X.XX.XX.42.02
en
STEP 515.8KB
825X.XX.XX.42.08
en
STEP 241.2KB
825X.XX.XX.42.22 24 88
en
STEP 384.8KB
825X.XX.XX.42.24
en
STEP 642.3KB
825X.XX.XX.42.32
en
STEP 1.2MB
825X.XX.XX.42.35
en
STEP 1.3MB
825X.XX.XX.42.D3
en
STEP 1.8MB
825X.XX.XX.42.D4
en
STEP 1.3MB
825X.XX.XX.43.01
en
STEP 1.4MB
825X.XX.XX.43.02
en
STEP 503KB
825X.XX.XX.43.08
en
STEP 228.3KB
825X.XX.XX.43.22 24 88
en
STEP 372KB
825X.XX.XX.43.32
en
STEP 1.2MB
825X.XX.XX.43.35
en
STEP 1.3MB
825X.XX.XX.43.D3
en
STEP 1.6MB
825X.XX.XX.43.D4
en
STEP 1.3MB
825X.XX.XX.44.01
en
STEP 1.4MB
825X.XX.XX.44.02
en
STEP 500.3KB
825X.XX.XX.44.08
en
STEP 225.6KB
825X.XX.XX.44.22 24 88
en
STEP 369.2KB
825X.XX.XX.44.32
en
STEP 1.2MB
825X.XX.XX.44.35
en
STEP 1.3MB
825X.XX.XX.44.D3
en
STEP 1.6MB
825X.XX.XX.44.D4
en
STEP 1.3MB
825X.XX.XX.49.01
en
STEP 1.4MB
825X.XX.XX.49.02
en
STEP 521.7KB
825X.XX.XX.49.08
en
STEP 247.1KB
825X.XX.XX.49.22 24 88
en
STEP 390.7KB
825X.XX.XX.49.32
en
STEP 1.2MB
825X.XX.XX.49.35
en
STEP 1.3MB
825X.XX.XX.49.D3
en
STEP 1.6MB
825X.XX.XX.49.D4
en
STEP 1.3MB
825X.XX.XX.53.01
en
STEP 1.4MB
825X.XX.XX.53.02
en
STEP 509.9KB
825X.XX.XX.53.08
en
STEP 235.2KB
825X.XX.XX.53.22 24 88
en
STEP 378.8KB
825X.XX.XX.53.32
en
STEP 1.2MB
825X.XX.XX.53.35
en
STEP 1.3MB
825X.XX.XX.53.D3
en
STEP 1.6MB
825X.XX.XX.53.D4
en
STEP 1.3MB

Did you not find the product information you were looking for? Please contact our sales team.

Standard variants of this product

Grouped product items

Product Name	Measuring range [bar]	Over pressure max. [bar]	Output signal

NAT6.0A

0 ... 6

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9...32

Pressure connection: G1/4" male

Type Code: 8252 77 2517 01 0000 0000 19 34 44 61

NAT10.0A

0 ... 10

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9...32

Pressure connection: G1/4" male

Type Code: 8252 78 2517 01 0000 0000 19 34 44 61

NAT400.0A

0 ... 400

1000

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 84 2517 01 0000 0000 19 34 44 61

NAT2.5A

0 ... 2.5

7.5

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 75 2517 01 0000 0000 19 34 44 61

NAT4.0A

0 ... 4

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 76 2517 01 0000 0000 19 34 44 61

NAT250.0A

0 ... 250

750

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 74 2517 01 0000 0000 19 34 44 61

NAT16.0A

0 ... 16

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 79 2517 01 0000 0000 19 34 44 61

NAT25.0A

0 ... 25

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 80 2517 01 0000 0000 19 34 44 61

NAT40.0A

0 ... 40

120

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0. 2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 81 2517 01 0000 0000 19 34 44 61

NAT100.0A

0 ... 100

300

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 83 2517 01 0000 0000 19 34 44 61

NAT600.0A

0 ... 600

1500

4 ...20 mA

Accuracy @ 25°C typ.: ±0.5

NLH @ 25°C (BSL) FS typ.: ±0.2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 86 2517 01 0000 0000 19 34 44 61

NAT2.5V

0 ... 2.5

7.5

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 75 2517 01 0000 0000 17 34 44 61

NAT4.0V

0 ... 4

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 76 2517 01 0000 0000 17 34 44 61

NAT6.0V

0 ... 6

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 77 2517 01 0000 0000 17 34 44 61

NAT10.0V

0 ... 10

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 78 2517 01 0000 0000 17 34 44 61

NAT16.0V

0 ... 16

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 79 2517 01 0000 0000 17 34 44 61

NAT25.0V

0 ... 25

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 80 2517 01 0000 0000 17 34 44 61

NAT40.0V

0 ... 40

120

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 81 2517 01 0000 0000 17 34 44 61

NAT100.0V

0 ... 100

300

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 83 2517 01 0000 0000 17 34 44 61

NAT250.0V

0 ... 250

750

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 74 2517 01 0000 0000 17 34 44 61

NAT400.0V

0 ... 400

1000

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 84 2517 01 0000 0000 17 34 44 61

NAT600.0V

0 ... 600

1500

0 ... 10 VDC

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 15 ... 32

Pressure connection: G1/4" male

Type Code: 8252 86 2517 01 0000 0000 17 34 44 61

NAT10.0AM

0 ... 10

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 78 2517 32 0000 0000 19 33 44 61

NAT100.0AM

0 ... 100

300

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 83 2517 32 0000 0000 19 33 44 61

NAT16.0AM

0 ... 16

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 79 2517 32 0000 0000 19 33 44 61

NAT160.0AM

0 ... 160

480

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 85 2517 32 0000 0000 19 33 44 61

NAT2.5AM

0 ... 2.5

7.5

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 75 2517 32 0000 0000 19 33 44 61

NAT25.0AM

0 ... 25

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 80 2517 32 0000 0000 19 33 44 61

NAT250.0AM

0 ... 250

750

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 74 2517 32 0000 0000 19 33 44 61

NAT4.0AM

0 ... 4

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 76 2517 32 0000 0000 19 33 44 61

NAT40.0AM

0 ... 40

120

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 81 2517 32 0000 0000 19 33 44 61

NAT400.0AM

0 ... 400

1000

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 84 2517 32 0000 0000 19 33 44 61

NAT6.0AM

0 ... 6

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 77 2517 32 0000 0000 19 33 44 61

NAT60.0AM

0 ... 60

180

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 82 2517 32 0000 0000 19 33 44 61

NAT600.0AM

0 ... 600

1500

4 ... 20 mA

Accuracy @ 25°C typ.: ±0.5

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8252 86 2517 32 0000 0000 19 33 44 61

Related products

Trafag is where you are

Please get in touch with us

I accept the privacy policy.

NAT 8252 Industrial Pressure Transmitter

Main features

Technical Data

Trafag is where you are

Please get in touch with us

Trafag AG

Products

Industries

Resources

Company
