MST 624/634

MST 624/634 Ministat

Back to overview

Skip to the end of the images gallery

main product photo

Skip to the beginning of the images gallery

Main features

Short response time
Protection IP54
Electrical connection on terminal screw

About

Technical Data

More Information
Product code	624/634
Name	MST
Designation	Ministat
Product category	Thermostats
Measuring range	-30°C ... +40°C to +70°C ... +350°C
Applications	HVAC Machine tools Process technology Water treatment
Repeatability	± 0.5 % FS typ.
Designation of application	Direct mounting thermostat
Approval / conformity	EN60730-1/ EN60730-2-9: Type 2.B.H
Output signal	Floating change-over contact
Ambient temperature	Range ≤ +45°C: -30°C ... +50°C Range +45°C ... +250°C: -30°C ... +70°C Range > + 250°C: -10°C ... +70°C (Important: Temperature at sensor may not exceed maximum sensortemperature)

Downloads Go to file downloads

Datasheet:

H72174p CN 624 634 MST Ministat
cn
pdf 420.3KB
H72174p DE 624 634 MST Ministat
de
pdf 359KB
H72174p EN 624 634 MST Ministat
en
pdf 358.1KB
H72174p ES 624 634 MST Ministat
es
pdf 358.8KB
H72174p FR 624 634 MST Ministat
fr
pdf 358.5KB
H72174p IT 624 634 MST Ministat
it
pdf 358.1KB
H72174p JP 624 634 MST Ministat
jp
pdf 426.9KB
H72174p PL 624 634 MST Ministat
pl
pdf 359.5KB
H72174p PT 624 634 MST Ministat
pt
pdf 359.2KB

Manual:

H73624e Ministat Instruction
en
pdf 503.9KB

Flyer:

H70955p CN 624 634 MST Ministat
cn
pdf 4.5MB
H70955p DE 624 634 MST Ministat
de
pdf 4.5MB
H70955p EN 624 634 MST Ministat
en
pdf 4.5MB
H70955p ES 624 634 MST Ministat
es
pdf 4.5MB
H70955p FR 624 634 MST Ministat
fr
pdf 4.5MB
H70955p IT 624 634 MST Ministat
it
pdf 4.5MB
H70955p JP 624 634 MST Ministat
jp
pdf 4.5MB
H70955p PL 624 634 MST Ministat
pl
pdf 4.5MB
H70955p PT 624 634 MST Ministat
pt
pdf 4.5MB

Certificates:

CE UKCA Declaration of conformity 1xx 3xx 4xx 5xx 6xx 7xx 87x6 87x8 9xx 990 991 992 993
en
pdf 74.2KB

Did you not find the product information you were looking for? Please contact our sales team.

Standard variants of this product

Grouped product items

Product Name	Temperature range [°C]	Sensor max. [°C]

+5 ... +95

105

Sensor: Capillary tube with direct mounted sensor

Set point adjustment: Internal switchpoint adjustment

Protection tube length: 150

Type Code: 634 2520 322 12 1216 0150

+5 ... +95

105

Sensor: Capillary tube with direct mounted sensor

Set point adjustment: Internal switchpoint adjustment

Protection tube length: 110

Type Code: 634 2520 332 12 1217 0110

-10 ... +80

85

Sensor: Capillary tube with direct mounted sensor

Set point adjustment: Internal switchpoint adjustment

Protection tube length: 150

Type Code: 634 2595 322 12 1216 0150

+20 ... +150

165

Sensor: Capillary tube with direct mounted sensor

Set point adjustment: Internal switchpoint adjustment

Protection tube length: 150

Type Code: 634 2531 122 12 1216 0150

-10 ... +80

85

Sensor: Capillary tube with direct mounted sensor

Set point adjustment: Internal switchpoint adjustment

Protection tube length: 400

Type Code: 634 2595 322 12 1216 0400

+5 ... +95

105

Sensor: Capillary tube with direct mounted sensor

Set point adjustment: Internal switchpoint adjustment

Protection tube length: 400

Type Code: 634 2520 322 12 1216 0400

+20 ... +150

165

Sensor: Capillary tube with direct mounted sensor

Set point adjustment: Internal switchpoint adjustment

Protection tube length: 400

Type Code: 634 2531 122 12 1216 0400
