Main features
- Steel or bronze bellows
- Blade connector (IEC) 2.8 x 0.5 mm
- Compact design
- Adjustment in factory
About
Technical Data
| Product code | 987/988 |
|---|---|
| Designation | Pressostat |
| Product category | Mechanical pressure switches |
| Measuring range | -0.3 ... 1.3 to 1 ... 10 bar |
| Measuring principle | Bellows |
| Applications | Machine toolsMedium voltage technology |
| Approval / conformity | EN60730-1/ EN60730-2-6: Type 2.B.H |
| Repeatability | ± 1.0 % FS typ. |
| Output signal | 1 or 2 floating change-over contacts (SPDT) |
| Electrical connections | Blade connector |
| Pressure connections | G1/4" m |
| Media temperature | -25°C ... +80°C |
| Ambient temperature | -25°C ... +70°C |
Downloads Go to file downloads
Datasheet:
-
H72272r CN 987 988 Pressostatcn
pdf 433.1KB
-
H72272r DE 987 988 Pressostatde
pdf 375.8KB
-
H72272r EN 987 988 Pressostaten
pdf 375KB
-
H72272r ES 987 988 Pressostates
pdf 375.4KB
-
H72272r FR 987 988 Pressostatfr
pdf 375.8KB
-
H72272r IT 987 988 Pressostatit
pdf 375.1KB
-
H72272r JP 987 988 Pressostatjp
pdf 438KB
-
H72272r PL 987 988 Pressostatpl
pdf 376.3KB
-
H72272r PT 987 988 Pressostatpt
pdf 376.2KB
Manual:
Flyer:
-
H70915r CN 987 988 Pressostatcn
pdf 3.5MB
-
H70915r DE 987 988 Pressostatde
pdf 3.5MB
-
H70915r EN 987 988 Pressostaten
pdf 3.5MB
-
H70915r ES 987 988 Pressostates
pdf 3.5MB
-
H70915r FR 987 988 Pressostatfr
pdf 3.5MB
-
H70915r IT 987 988 Pressostatit
pdf 3.5MB
-
H70915r JP 987 988 Pressostatjp
pdf 3.5MB
-
H70915r PL 987 988 Pressostatpl
pdf 3.5MB
-
H70915r PT 987 988 Pressostatpt
pdf 3.5MB
Certificates:
Did you not find the product information you were looking for? Please contact our sales team.
