Main features
- Exact switching output at all temperatures
- Fully temperature compensated by design
- No contact bouncing
- Continuous density measurement
- Long term drift free sensor output signal
- Maintenance free indoor and outdoor use
About
Swiss based Trafag offers precise, reliable and maintenance-free instruments, developed for density monitoring of SF6 and alternative gases. Measurement is based on the gas density reference principle or the patented quartz tuning fork technology. Hybrid monitors combine both principles in one instrument. Thus offering the most reliable solution on the market by directly measuring the gas density.
Technical Data
| Product code | 878x |
|---|---|
| Designation | Hybrid gas density monitor with switching contacts and current output |
| Measuring range | max. 0 ... 60 kg/m3 |
| Measuring principle |
|
| Designation of application | Density monitoring and measurement in insulating and quenching gas |
| Output signal |
|
| Ambient temperature | -40°C ... +80°C |
| Applications | Medium voltage technologySF6 and variety of alternative mixed gases |
