Main features
- Compact design
- Rugged housing
- Protection IP65
- Any mounting position possible
- May be used as „simple apparatus“ in zones at risk of explosions
About
Technical Data
| Product code | 904 |
|---|---|
| Name | «Simple Apparatus» conformity to ATEX |
| Designation | Pressostat |
| Product category | Mechanical pressure switches |
| Measuring range | -0.9 ... 1.5 to 10 ... 100 bar |
| Measuring principle | Bellows |
| Designation of application | Industrial pressostat |
| Applications | Potentially hazardous areas |
| Approval / conformity | EN60730-1/ EN60730-2-6: Typ 2.B.H EN60079-0, EN60079-11 Zone 1 and 2, 21 and 22 |
| Repeatability | ± 1.0 % FS typ. |
| Output signal | 1 Floating change-over contact (SPDT) |
| Media temperature | -40°C ... +150°C |
| Ambient temperature | -25°C ... +70°C |
Downloads Go to file downloads
Datasheet:
-
H72364e CN 904 Simple Apparatus conformity to ATEX Pressostatcn
pdf 445KB
-
H72364e DE 904 Simple Apparatus conformity to ATEX Pressostatde
pdf 383.4KB
-
H72364e EN 904 Simple Apparatus conformity to ATEX Pressostaten
pdf 380.9KB
-
H72364e ES 904 Simple Apparatus conformity to ATEX Pressostates
pdf 381.6KB
-
H72364e FR 904 Simple Apparatus conformity to ATEX Pressostatfr
pdf 382.2KB
-
H72364e IT 904 Simple Apparatus conformity to ATEX Pressostatit
pdf 381.1KB
-
H72364e JP 904 Simple Apparatus conformity to ATEX Pressostatjp
pdf 446.7KB
-
H72364e PL 904 Simple Apparatus conformity to ATEX Pressostatpl
pdf 382.9KB
-
H72364e PT 904 Simple Apparatus conformity to ATEX Pressostatpt
pdf 382.5KB
Manual:
Flyer:
-
H70919e CN 904 Simple Apparatus conformity to ATEX Pressostatcn
pdf 3.5MB
-
H70919e DE 904 Simple Apparatus conformity to ATEX Pressostatde
pdf 3.5MB
-
H70919e EN 904 Simple Apparatus conformity to ATEX Pressostaten
pdf 3.5MB
-
H70919e ES 904 Simple Apparatus conformity to ATEX Pressostates
pdf 3.5MB
-
H70919e FR 904 Simple Apparatus conformity to ATEX Pressostatfr
pdf 3.5MB
-
H70919e IT 904 Simple Apparatus conformity to ATEX Pressostatit
pdf 3.5MB
-
H70919e JP 904 Simple Apparatus conformity to ATEX Pressostatjp
pdf 3.5MB
-
H70919e PL 904 Simple Apparatus conformity to ATEX Pressostatpl
pdf 3.5MB
-
H70919e PT 904 Simple Apparatus conformity to ATEX Pressostatpt
pdf 3.5MB
Certificates:
