NAE 8256 Marine Pressure Transmitter

Back to overview

Shipbuilding

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Main features

Measuring accuracy 0.3 %
Completely welded steel sensor system without additional seals
High resistance to over pressure
Excellent long-term stability
Optional: Switching output 1 or 2 PNP

About

The engine and shipbuilding pressure transmitter NAE 8256 features the extremely robust and stable thin-film-on-steel sensor element. The NAE 8256 is the smallest pressure transmitter of its kind with ship approvals. The wide temperature range from -40°C up to +125°C and triple overpressure safety makes it the first choice in rough environments such as marine applications.

Technical Data

More Information
Product code	8256
Name	NAE
Designation	Marine Pressure Transmitter
Product category	Pressure transmitters
Measuring range	0 ... 6 to 0 ... 700 bar 0 ... 100 to 0 ... 10000 psi
Measuring principle	Thin-film-on-steel
Approval / conformity	DNV EU RO Mutual Recognition Type Approval Certificate
Accuracy @ 25°C typ.	0.3 %: ± 0.3 % FS typ.
Output signal	4 ... 20 mA, Switching output: 1 or 2 PNP
Electrical connections	M12x1; Cable IP67/IP68
Pressure connections	G1/4" m; G1/4" m (Manometer EN 837); G1/8" a, DIN3852-E; 1/4"NPT m; M10x1 m
Media temperature	–40°C ... +125°C
Ambient temperature	–40°C ... +125°C (cable Radox Tenuis 88: -40°C ... +100°C)
Measuring range	≤ 1 bar ≤ 100 bar ≤ 600 bar < 15 psi < 1500 psi < 7500 psi Relative pressure

Downloads Go to file downloads

Datasheet:

H72305p CN 8256 NAE Marine Pressure Transmitter
cn
pdf 802.5KB
H72305p DE 8256 NAE Marine Pressure Transmitter
de
pdf 718.1KB
H72305p EN 8256 NAE Marine Pressure Transmitter
en
pdf 717.1KB
H72305p ES 8256 NAE Marine Pressure Transmitter
es
pdf 720.1KB
H72305p FR 8256 NAE Marine Pressure Transmitter
fr
pdf 720KB
H72305p IT 8256 NAE Marine Pressure Transmitter
it
pdf 712.1KB
H72305p JP 8256 NAE Marine Pressure Transmitter
jp
pdf 813.6KB
H72305p PL 8256 NAE Marine Pressure Transmitter
pl
pdf 721KB
H72305p PT 8256 NAE Marine Pressure Transmitter
pt
pdf 720.8KB

Manual:

H73303ab Instructions 8250 8252 8254 8256 8258 NHT NAT NAH NAE NAR Pressure Transmitter A5
en
pdf 889KB

Flyer:

H70684p CN 8256 NAE Marine Pressure Transmitter
cn
pdf 4.7MB
H70684p DE 8256 NAE Marine Pressure Transmitter
de
pdf 4.7MB
H70684p EN 8256 NAE Marine Pressure Transmitter
en
pdf 4.7MB
H70684p ES 8256 NAE Marine Pressure Transmitter
es
pdf 4.7MB
H70684p FR 8256 NAE Marine Pressure Transmitter
fr
pdf 4.7MB
H70684p IT 8256 NAE Marine Pressure Transmitter
it
pdf 4.7MB
H70684p JP 8256 NAE Marine Pressure Transmitter
jp
pdf 4.7MB
H70684p PL 8256 NAE Marine Pressure Transmitter
pl
pdf 4.7MB
H70684p PT 8256 NAE Marine Pressure Transmitter
pt
pdf 4.7MB

Certificates:

CE UKCA Declaration of conformity Pressure Transmitter
en
pdf 73.9KB
DNVGL MR NAE 8256
en
pdf 73KB

STEP files and software:

825X.XX.XX.17.01
en
STEP 1.4MB
825X.XX.XX.17.32
en
STEP 1.2MB
825X.XX.XX.17.35
en
STEP 1.3MB
825X.XX.XX.30.01
en
STEP 1.4MB
825X.XX.XX.30.32
en
STEP 1.2MB
825X.XX.XX.30.35
en
STEP 1.3MB
825X.XX.XX.32.01
en
STEP 1.4MB
825X.XX.XX.32.32
en
STEP 1.3MB
825X.XX.XX.32.35
en
STEP 1.3MB
825X.XX.XX.53.01
en
STEP 1.4MB
825X.XX.XX.53.32
en
STEP 1.2MB
825X.XX.XX.53.35
en
STEP 1.3MB

Did you not find the product information you were looking for? Please contact our sales team.

Standard variants of this product

Grouped product items

Product Name	Measuring range [bar]	Over pressure max. [bar]	Output signal

NAE10.0A

0 ... 10

4 ... 20 mA

Accuracy @ 25°C typ.: ± 0.3

NLH @ 25°C (BSL) FS typ.: 0.5 %: ± 0.2 % FS typ. 0.3 %: ± 0.2 % FS typ.

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8256 78 2317 32 0000 0000 19 33 44 61

NAE16.0A

0 ... 16

4 ... 20 mA

Accuracy @ 25°C typ.: ± 0.3

NLH @ 25°C (BSL) FS typ.: 0.5 %: ± 0.2 % FS typ. 0.3 %: ± 0.2 % FS typ.

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8256 79 2317 32 0000 0000 19 33 44 61

NAE25.0A

0 ... 25

4 ... 20 mA

Accuracy @ 25°C typ.: ± 0.3

NLH @ 25°C (BSL) FS typ.: 0.5 %: ± 0.2 % FS typ. 0.3 %: ± 0.2 % FS typ.

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8256 80 2317 32 0000 0000 19 33 44 61

NAE40.0A

0 ... 40

120

4 ... 20 mA

Accuracy @ 25°C typ.: ± 0.3

NLH @ 25°C (BSL) FS typ.: 0.5 %: ± 0.2 % FS typ. 0.3 %: ± 0.2 % FS typ.

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8256 81 2317 32 0000 0000 19 33 44 61

NAE100.0A

0 ... 100

300

4 ... 20 mA

Accuracy @ 25°C typ.: ± 0.3

NLH @ 25°C (BSL) FS typ.: 0.5 %: ± 0.2 % FS typ. 0.3 %: ± 0.2 % FS typ.

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8256 83 2317 32 0000 0000 19 33 44 61

NAE250.0A

0 ... 250

750

4 ... 20 mA

Accuracy @ 25°C typ.: ± 0.3

NLH @ 25°C (BSL) FS typ.: 0.5 %: ± 0.2 % FS typ. 0.3 %: ± 0.2 % FS typ.

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8256 74 2317 32 0000 0000 19 33 44 61

NAE400.0A

0 ... 400

1000

4 ... 20 mA

Accuracy @ 25°C typ.: ± 0.3

NLH @ 25°C (BSL) FS typ.: 0.5 %: ± 0.2 % FS typ. 0.3 %: ± 0.2 % FS typ.

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8256 84 2317 32 0000 0000 19 33 44 61

NAE600.0A

0 ... 600

1500

4 ... 20 mA

Accuracy @ 25°C typ.: ± 0.3

NLH @ 25°C (BSL) FS typ.: 0.5 %: ± 0.2 % FS typ. 0.3 %: ± 0.2 % FS typ.

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8256 86 2317 32 0000 0000 19 33 44 61

NAE6.0A

0 ... 6

4 ... 20 mA

Accuracy @ 25°C typ.: ± 0.3

NLH @ 25°C (BSL) FS typ.: ± 0.2

Supply [VDC]: 9 ... 32

Pressure connection: G1/4" male

Type Code: 8256 77 2317 32 0000 0000 19 33 44 61
