Main features
- Rugged aluminium housing
- Protection IP 65
- Diverse mounting positions
About
Technical Data
| Product code | 944/947 |
|---|---|
| Name | PK |
| Designation | Pressostat |
| Product category | Mechanical pressure switches |
| Measuring range | 1 ... 10 to 60 ... 600 bar |
| Measuring principle | Piston |
| Approval / conformity | ABS, BV, CCS, DNV, KRS, LRS, RINA EN60730-1/EN60730-2-6: Type 2.B.H |
| Repeatability | ± 1.0 % FS typ. |
| Output signal | 1 Floating change-over contact (SPDT) |
| Electrical connections | Screw terminal |
| Pressure connections | G1/4 f, G1/2 m |
| Media temperature | O-Ring NBR: -30°C ... +100°C O-Ring FKM: -15°C ... +150°C |
| Ambient temperature | -20°C ... +70°C |
Downloads Go to file downloads
Datasheet:
-
H72259t CN 944 947 PK Pressostatcn
pdf 524.1KB
-
H72259t DE 944 947 PK Pressostatde
pdf 464KB
-
H72259t EN 944 947 PK Pressostaten
pdf 447.3KB
-
H72259t ES 944 947 PK Pressostates
pdf 463.5KB
-
H72259t FR 944 947 PK Pressostatfr
pdf 447.9KB
-
H72259t IT 944 947 PK Pressostatit
pdf 463KB
-
H72259t JP 944 947 PK Pressostatjp
pdf 532.3KB
-
H72259t PL 944 947 PK Pressostatpl
pdf 464.7KB
-
H72259t PT 944 947 PK Pressostatpt
pdf 464.5KB
Manual:
Certificates:
-
CE UKCA Declaration of conformity 9xxen
pdf 68.1KB
-
IECEx SEV 170013X P-Switchen
pdf 1.3MB
-
SEV 15 ATEX 0157 X en P-Switch Issue2en
pdf 3.5MB
Did you not find the product information you were looking for? Please contact our sales team.
