Main features
- Compact design
- Rugged housing
- Diverse mounting positions
- Ex db eb IIC T6 Gb
- Ex tb IIIC T80°C Db
About
Technical Data
| Product code | 404/414 |
|---|---|
| Name | EXS |
| Designation | Ex Industat |
| Product category | Thermostats |
| Measuring range | -30°C ... +40°C to +70°C ... +350°C |
| Repeatability | ± 0.5 % FS typ. |
| Designation of application | Ex industrial thermostat with remote sensor |
| Approval / conformity | IECEx, ATEX, UKEX |
| Output signal | Floating change-over contact |
| Ambient temperature | Range ≤ +45°C: -30°C ... +50°C Range +45°C ... +250°C: -30°C ... +60°C Range > + 250°C: -10°C ... +60°C |
Downloads Go to file downloads
Datasheet:
-
H72108y CN 404 414 EXS Ex Industatcn
pdf 474KB
-
H72108z EN 404 414 EXS Ex Industaten
pdf 409.7KB
Manual:
Certificates:
-
CE UKCA Declaration of conformity 404 414 409 419 EXS EXASen
pdf 68.6KB
-
IECEx SEV 170010X T-Switchen
pdf 1.5MB
-
SEV 15 ATEX 0156 X en T-Switch Issue2en
pdf 3.4MB
Did you not find the product information you were looking for? Please contact our sales team.
