Main features
- Steel or bronze bellow
- Blade connector (IEC) 2.8 x 0.5 mm
- Compact design
- Adjustment in factory
About
Technical Data
| Product code | 987/988 |
|---|---|
| Designation | Pressostat |
| Product category | Mechanical pressure switches |
| Measuring range | -0.3 ... 1.3 to 1 ... 10 bar |
| Measuring principle | Bellow |
| Approval / conformity | EN60730-1/ EN60730-2-6: Type 2.B.H |
| Repeatability | ± 1.0 % FS typ. |
| Output signal | 1 or 2 floating change-over contacts (SPDT) |
| Electrical connections | Blade connector |
| Pressure connections | G1/4 m |
| Media temperature | -25°C ... +80°C |
| Ambient temperature | -25°C ... +70°C |
Downloads Go to file downloads
Datasheet:
-
H72272u CN 987 988 Pressostatcn
pdf 422.2KB
-
H72272u DE 987 988 Pressostatde
pdf 363.2KB
-
H72272u EN 987 988 Pressostaten
pdf 362.6KB
-
H72272u ES 987 988 Pressostates
pdf 362.9KB
-
H72272u FR 987 988 Pressostatfr
pdf 363.4KB
-
H72272u IT 987 988 Pressostatit
pdf 362.5KB
-
H72272u JP 987 988 Pressostatjp
pdf 428.4KB
-
H72272u PL 987 988 Pressostatpl
pdf 363.9KB
-
H72272u PT 987 988 Pressostatpt
pdf 363.6KB
Manual:
Certificates:
-
CE UKCA Declaration of conformity 9xxen
pdf 68.1KB
-
BV Pressostats 9xx Seriesen
pdf 1.1MB
-
CCS Pressure Switch 9xxen
pdf 268.1KB
-
DNVGL Pressure Switch 9XXen
pdf 171.5KB
-
RINA Pressure Switches 9xxen
pdf 1.7MB
