Main features
- Solid front with full blow back
- All stainless steel measuring system
- External zero adjustment
- Dry / liquid filled
About
The TMP203 High Safety Pressure Gauge in miniature design DN63 is ideally suited where space is tight.
Technical Data
| Product code | 203 |
|---|---|
| Name | TMP |
| Designation | High safety pressure gauge |
| Measuring range | -1 ... 0 to 0 ... 1000 bar |
| Measuring principle | Bourdon Tube (≤100 bar: C - type, >100 bar: Helical) |
| Approval / conformity | EN 837-1, ATEX 2014/34/UE |
Downloads Go to file downloads
Datasheet:
Certificates:
