Main features
- Measuring resolution 5, 10, 20 mm
- Analogue output 4 ... 20 mA, 0 ... 5 VDC, 0 ... 10 VDC
- Optional : Temperature sensor PT1000
- Protection IP 65
About
The principle of operation is of potentiometric type, based on the gradual shutdown of a chain of resistors and Reed contacts, placed inside the guiding rod, by a magnetic float. An analogue output signal is provided with a measuring resolution of 5, 10 or 20 mm.
Technical Data
| Product code | TFC |
|---|---|
| Name | TFC |
| Designation | Float Level Sensor |
| Measuring range | max. 2000 mm |
| Measuring principle | Float activated Reed contacts |
Downloads Go to file downloads
Datasheet:
-
H20040e EN TFC Float Level Sensoren
pdf 578.8KB
Manual:
-
H21040 Float-level TFS-TFCen
pdf 1.5MB
