Main features
- Measuring accuracy 0.3 %
- Optional: Switching output 1 or 2 PNP
- Excellent long-term stability
- Meets EN 50155 (Railway)
About
The pressure transmitter NAR 8258 with increased accuracy of 0.3 % was specifically designed for railway vehicles (EN 50155) and has a long-term stable thin-film-on-steel sensor cell. The wide temperature range from -40°C to +85°C and the triple overpressure protection make the NAR 8258 the ideal choice for railway vehicles in rough environmental conditions.
Technical Data
| Product code | 8258 |
|---|---|
| Name | NAR |
| Designation | Railway Pressure Transmitter |
| Product category | Pressure transmitters |
| Measuring range | 0 ... 6 to 0 ... 700 bar 0 ... 100 to 0 ... 10000 psi |
| Measuring principle | Thin-film-on-steel |
| Approval / conformity | EN 50155 (Railway) EN 45545-2 (Fire protection) EN 61373 (Shock, vibration) EN 50121-3-2 (EMC) |
| Accuracy @ 25°C typ. | ± 0.3 % FS typ. |
| Output signal | 4 ... 20 mA, Switching output: 1 or 2 PNP |
| Electrical connections | Industrial standard, contact distance 9.4 mm; M12x1; Cable IP67, IP68 |
| Pressure connections | G1/4 m; |
| Media temperature | -40°C ... +85°C |
| Ambient temperature | -40°C ... +85°C (EN 50155: OT6) |
| Output signal | 4 … 20 mA1 PNP Switch2 PNP Switch |
| Special features | Compact design |
